Drakflag 500

$ 39,888

• Displacement (c.c)496Bore x stroke (mm)ø53.5×55.2Compression ratio11.5:1Fuel systemEFIValve trainDOHCIgnitionT.C.IStarterElectricLubrication systemPressure splash lubricationCooling systemLiquid-cooled

Displacement (c.c)

496

Bore x stroke (mm)

ø53.5×55.2

Compression ratio

11.5:1

Fuel system

EFI

Valve train

DOHC

Ignition

T.C.I

Starter

Electric

Lubrication system

Pressure splash lubrication

Cooling system

Liquid-cooled

• Gearbox6-speedFinal driveBeltClutch typeSlipper clutch

Gearbox

6-speed

Final drive

Belt

Clutch type

Slipper clutch

• Front wheelAluminum alloyFront suspensionUpside-down telescopic forksFront suspension travel (mm)95Front tyre130/90-16Rear wheelAluminum alloyRear suspensionAirmaticRear suspension travel (mm)61.5Rear tyre150/80-16Front brakesDisc Brakes with ABS systemFront brakes diameter (mm)320Rear brakesDisc Brake with ABS systemRear brakes diameter (mm)260

Front wheel

Aluminum alloy

Front suspension

Upside-down telescopic forks

Front suspension travel (mm)

95

Front tyre

130/90-16

Rear wheel

Aluminum alloy

Rear suspension

Airmatic

Rear suspension travel (mm)

61.5

Rear tyre

150/80-16

Front brakes

Disc Brakes with ABS system

Front brakes diameter (mm)

320

Rear brakes

Disc Brake with ABS system

Rear brakes diameter (mm)

260

• Seat height (mm)700Overall LxWxH (mm)2330×800×1267Ground clearance (mm)133Wheelbase (mm)1586Top speed (km/h)145Max. load (kg)180Fuel capacity (L)16

Seat height (mm)

700

Overall LxWxH (mm)

2330×800×1267

Ground clearance (mm)

133

Wheelbase (mm)

1586

Top speed (km/h)

145

Max. load (kg)

180

Fuel capacity (L)

16
